Hydraulic Oil Press Machine
- Stainless steel, Chrome plated;
- Low energy consumption, High oil yield, Pure oil, No filtration;
- High pressure(60Mpa), Can save 60% labor;
Brochure
Overview
Gallery
Features
Material Solution
Specifications
Projects
Information Request
Overview
Our hydraulic oil press machines utilize advanced hydraulic technology to maximize oil yield. The high pressure generated during the pressing process ensures optimal extraction while minimizing oil loss, providing a superior product.
Gallery
Structure of hydraulic oil press machine
1. Main engine:Main engine includes base, upright, top plate, oil drip pan nut and so on , it is one of the main parts.
2. Hydraulic System :Hydraulic system is the main power force of this machine, it includes transmission shaft, turbine, worm gear, gear pump, high pressure pump, overflow valve; super high pressure safety valve; hand-operated valve; seamless steel tube; pipeline connect and other spare parts.
3. Electronic system: This machine is composed of motor, volt meter, pressure gauge, power insurance and so on.
Features
Durable Construction: Built with high-quality stainless steel and cast iron.
Safety Features: include such as pressure relief valves and secure door locks, to ensure safe operation.
User-Friendly Operation: Featuring intuitive controls and a clear display, are easy to operate.
Material Solution
Almost all of the oil crops can be squeezed through the press. Includes peanuts, soybeans, sunflower, rapeseed, walnut, cottonseed, and more.
Technical Specifications
| Model | YZYJ-240(10KG) | YZYJ-270(13KG) | YZYJ-285(15KG) | YZYJ-300(17KG) | YZYJ-340(20KG) | YZYJ-360(25KG) |
| Process Capacity | 1.2T/24H | 1.6T/24H | 1.8T/24H | 2.0T/24H | 2.1T/24H | 2.4T/24H |
| Size（L*W*H ） | 950*850*1550mm | 1040*850*1550mm | 1100*950*1590mm | 1230*1120*1630mm | 1128*820*1600mm | 1370*950*1720mm |
| Weight | 1000KG | 1300KG | 1550KG | 1700KG | 1800KG | 2500KG |
| Voltage | 380v | 380v | 380v | 380v | 380v | 380v |
| Moto Power | 1.5KW-4 | 1.5KW-4 | 1.5KW-4 | 2.2KW-6 | 2.2KW-4 | 3KW-6 |
